Full Automatic PLC Controlled Coil Winding System High Efficiency Precise Stable for PP Electric Motor
Products Description
The Full Automatic PLC Controlled Coil Winding System is a high-efficiency, precision-engineered solution built to meet the demanding needs of PP electric motor coil production. Designed for manufacturers seeking stable performance, accurate winding, and continuous automated operation, this system ensures consistent coil quality, reduced labor costs, and long-term reliability.
Advanced Technology for Precision Winding: At the heart of this system is a PLC (Programmable Logic Controller) that enables real-time control over every aspect of the winding process. Paired with a servo motor drive, it delivers smooth speed transitions and accurate wire placement, ensuring tightly wound, evenly layered coils. The system is specially configured to handle polypropylene (PP)-insulated copper or aluminum wire, maintaining insulation integrity while achieving maximum coil density and performance.
Its fully automatic operation means minimal manual intervention, resulting in faster cycle times and fewer errors. A robust steel frame and vibration-dampening structure allow the machine to run continuously under heavy industrial loads, while intuitive controls simplify setup and operation.
Main specifications and parameters
| Appearance and dimensions | 1950mm*1300mm*1600mm | Maximum winding diameter | 500MM |
| Machine weight | About 400KG | Rewind-up range | 8MM-20MM |
| Input power | 220V | Length of paper tube | ≤200MM |
| Maximum power | 2 KW | Equipment model | PPFA |
| Maximum operating pressure of the system | 0.8MPa | Minimum operating pressure of the system | 0.6MPa |
1Q: How do you make sure the machine quality?
To make sure the machine is qualified before deliver to our customer,we always arrange productiontesting,customer can assign the testing strap's specification.Customer could join the testing process orwe can provide video to show customer.
2Q: Do you have a professional team for the development of mechanical equipment?
Our R&D team comprises seasoned engineers and specialists from the plastic machinery sector. We have independently developed and manufactured the first fully intelligent strapping winders in China, exporting our products to Europe, the United States, and other regions.
3Q: What are the advantages of your strapping and packaging equipment?
Yicheng Automation,Committed to innovation, we continuously developing cutting-edge technologies in the packaging plastics machinery sector. With specialized expertise in fully intelligent plastic strapping rewinding systems, we deliver high cost-performance solutions engineered for customer success.
4Q: What are your after-sales services?
Warranty: One year from the delivery date indicated on the Bill of Lading (B/L).
During the warranty period, the seller will provide free parts and online service, except for any exclusions.
After the warranty period, the seller will supply parts at a cost.
Lifelong responsibility.
